style of the fingers

space at the start and end in multiple of normal spaces

height of the bottom lips sticking out (multiples of thickness) FingerHoleEdge only!

space below holes of FingerHoleEdge (multiples of thickness)

extra material to grind away burn marks (multiples of thickness)

width of the fingers (multiples of thickness)

extra space to allow finger move in and out (multiples of thickness)

space between fingers (multiples of thickness)

width of finger holes (multiples of thickness)

Height of the phone.

Width of the phone.

Depth of the phone. Used by the bottom support holding the phone, and the side tabs depth as well. Should be at least your material thickness for assembly reasons.

angle at which the phone stands, in degrees. 0° is vertical.

Height of the support below the phone

Length of the tabs holding the phone

Spacing between the two bottom support. Choose a value big enough for the charging cable, without getting in the way of other ports.

thickness of the material (in mm) 🛈

burn correction (in mm)(bigger values for tighter fit) 🛈

format of resulting file 🛈

label the parts (where available)

print reference rectangle with given length (in mm)(zero to disable) 🛈

width of tabs holding the parts in place (in mm)(not supported everywhere) 🛈

Add a QR Code with link or command line to the generated output

style for inner corners 🛈

spacing around parts (multiples of thickness [: extra space in mm]) 🛈

print surrounding boxes for some structures 🛈
